COSIMA: Preliminary model of the instrument

At left hand side is the box with the target (sample) manipulator; the diagonal part is the primary ion beam source (PIBS); the rectangular horizontal tube (with the nice pattern) is the secondary ion flight tube. Sulden Meeting, Glurns/Glorenza, Italy (March 1999)
